Base class for symbolic expression nodes.
Every node has a specified width measured in bits that is constant over the life of the node. The width is always a concrete, positive value stored in a 64bit field. The corollary of this invariant is that if an expression's result width depends on the values of some of its arguments, those arguments must be concrete and not wider than 64 bits. Only a few operators fall into this category since most expressions depend on the widths of their arguments rather than the values of their arguments.
In order that subtrees can be freely assigned as children of other nodes (provided the structure as a whole remains a lattice and not a graph with cycles), two things are required: First, tree nodes are always referenced through sharedownership pointers that collectively own the expression node (expressions are never explicitly deleted). Second, expression nodes are immutable once they're instantiated. There are a handful of exceptions to the immutable rule: comments and attributes are allowed to change since they're not significant to hashing or arithmetic operations.
Each node has a bit flags property, the bits of which are defined by the user. New nodes are created having all bits cleared unless the user specifies a value in the constructor. Bits are significant for hashing. Simplifiers produce result expressions whose bits are set in a predictable manner with the following rules:
add
operation.(ule v1 v1)
results in true with flags the same as v1
. Definition at line 214 of file BinarySymbolicExpr.h.
#include <BinarySymbolicExpr.h>
Classes
class  WithFormatter
A node with formatter. More...
Public Member Functions
virtual bool  mustEqual (const Ptr &other, const SmtSolverPtr &solver=SmtSolverPtr())=0
Returns true if two expressions must be equal (cannot be unequal). More...
virtual bool  mayEqual (const Ptr &other, const SmtSolverPtr &solver=SmtSolverPtr())=0
Returns true if two expressions might be equal, but not necessarily be equal. More...
virtual bool  isEquivalentTo (const Ptr &other)=0
Tests two expressions for structural equivalence. More...
virtual int  compareStructure (const Ptr &other)=0
Compare two expressions structurally for sorting. More...
virtual Ptr  substitute (const Ptr &from, const Ptr &to, const SmtSolverPtr &solver=SmtSolverPtr())=0
Substitute one value for another. More...
Ptr  substituteMultiple (const ExprExprHashMap &substitutions, const SmtSolverPtr &solver=SmtSolverPtr())
Rewrite expression by substituting subexpressions. More...
Ptr  renameVariables (ExprExprHashMap &index, size_t &nextVariableId, const SmtSolverPtr &solver=SmtSolverPtr())
Rewrite using lowest numbered variable names. More...
virtual bool  isNumber ()=0
Returns true if the expression is a known numeric value. More...
bool  is_known () ROSE_DEPRECATED("use isNumber instead")
virtual uint64_t  toInt ()=0
Property: integer value of expression node. More...
uint64_t  get_value () ROSE_DEPRECATED("use toInt instead")
const std::string &  get_comment () ROSE_DEPRECATED("use 'comment' property instead")
void  set_comment (const std::string &s) ROSE_DEPRECATED("use 'comment' property instead")
size_t  nBits ()
Property: Number of significant bits. More...
size_t  get_nbits () ROSE_DEPRECATED("use 'nBits' property instead")
unsigned  flags ()
Property: Userdefined bit flags. More...
unsigned  get_flags () ROSE_DEPRECATED("use 'flags' property instead")
Ptr  newFlags (unsigned flags)
Sets flags. More...
size_t  domainWidth ()
Property: Width for memory expressions. More...
bool  isScalar ()
Check whether expression is scalar. More...
virtual VisitAction  depthFirstTraversal (Visitor &)=0
Traverse the expression. More...
VisitAction  depth_first_traversal (Visitor &v) ROSE_DEPRECATED("use depthFirstTraversal instead")
virtual uint64_t  nNodes ()=0
Computes the size of an expression by counting the number of nodes. More...
uint64_t  nnodes () ROSE_DEPRECATED("use nNodes() instead")
uint64_t  nNodesUnique ()
Number of unique nodes in expression. More...
uint64_t  nnodesUnique () ROSE_DEPRECATED("use nNodesUnique instead")
std::set< LeafPtr >  getVariables ()
Returns the variables appearing in the expression. More...
std::set< LeafPtr >  get_variables () ROSE_DEPRECATED("use getVariables instead")
InteriorPtr  isInteriorNode ()
Dynamic cast of this object to an interior node. More...
InteriorPtr  isInternalNode () ROSE_DEPRECATED("use isInteriorNode instead")
LeafPtr  isLeafNode ()
Dynamic cast of this object to a leaf node. More...
bool  isHashed ()
Returns true if this node has a hash value computed and cached. More...
bool  is_hashed () ROSE_DEPRECATED("use isHashed instead")
Hash  hash ()
Returns (and caches) the hash value for this node. More...
void  hash (Hash)
WithFormatter  with_format (Formatter &fmt) ROSE_DEPRECATED("use withFormat instead")
void  assertAcyclic ()
Asserts that expressions are acyclic. More...
void  assert_acyclic ()
std::vector< Ptr >  findCommonSubexpressions ()
Find common subexpressions. More...
bool  matchAddVariableConstant (LeafPtr &variable, LeafPtr &constant)
Determine whether an expression is a variable plus a constant. More...
InteriorPtr  isOperator (Operator)
True (nonnull) if this node is the specified operator. More...
const std::string &  comment ()
Property: Comment. More...
void  comment (const std::string &s)
Property: Comment. More...
void  userData (boost::any &data)
Property: Userdefined data. More...
const boost::any &  userData ()
Property: Userdefined data. More...
WithFormatter  withFormat (Formatter &fmt)
Combines a node with a formatter for printing. More...
WithFormatter  operator+ (Formatter &fmt)
Combines a node with a formatter for printing. More...
virtual void  print (std::ostream &, Formatter &)=0
Print the expression to a stream. More...
void  print (std::ostream &o)
Print the expression to a stream. More...
Public Member Functions inherited from Sawyer::SharedObject
SharedObject ()
Default constructor. More...
SharedObject (const SharedObject &)
Copy constructor. More...
virtual  ~SharedObject ()
Virtual destructor. More...
SharedObject &  operator= (const SharedObject &)
Assignment. More...
Public Member Functions inherited from Sawyer::SharedFromThis< Node >
SharedPointer< Node >  sharedFromThis ()
Create a shared pointer from this . More...
SharedPointer< const Node >  sharedFromThis () const
Create a shared pointer from this . More...
Public Member Functions inherited from Sawyer::Attribute::Storage<>
Storage ()
Default constructor. More...
Storage (const Storage &other)
Copy constructor. More...
Storage &  operator= (const Storage &other)
Assignment operator. More...
bool  attributeExists (Id id) const
Check attribute existence. More...
void  eraseAttribute (Id id)
Erase an attribute. More...
void  clearAttributes ()
Erase all attributes. More...
void  setAttribute (Id id, const T &value)
Store an attribute. More...
bool  setAttributeMaybe (Id id, const T &value)
Store an attribute if not already present. More...
T  getAttribute (Id id) const
Get an attribute that is known to exist. More...
T  attributeOrElse (Id id, const T &dflt) const
Return an attribute or a specified value. More...
T  attributeOrDefault (Id id) const
Return an attribute or a defaultconstructed value. More...
Sawyer::Optional< T >  optionalAttribute (Id id) const
Return the attribute as an optional value. More...
size_t  nAttributes () const
Number of attributes stored. More...
std::vector< Id >  attributeIds () const
Returns ID numbers for all IDs stored in this container. More...
Static Public Attributes
static const unsigned  RESERVED_FLAGS = 0x0000ffff
These flags are reserved for use within ROSE. More...
static const unsigned  INDETERMINATE = 0x00000001
Value is somehow indeterminate. More...
static const unsigned  UNSPECIFIED = 0x00000002
Value is somehow unspecified. More...
static const unsigned  BOTTOM = 0x00000004
Value represents bottom in dataflow analysis. More...
static boost::logic::tribool(*  mayEqualCallback )(const Ptr &a, const Ptr &b, const SmtSolverPtr &)
Usersupplied predicate to augment alias checking. More...
Protected Member Functions
Node (const std::string &comment, unsigned flags=0)
void  printFlags (std::ostream &o, unsigned flags, char &bracket)
Protected Attributes
size_t  nBits_
Number of significant bits. More...
size_t  domainWidth_
Width of domain for unary functions. More...
unsigned  flags_
Bit flags. More...
std::string  comment_
Optional comment. More...
Hash  hashval_
Optional hash used as a quick way to indicate that two expressions are different. More...
boost::any  userData_
Additional userspecified data. More...
Additional Inherited Members
Public Types inherited from Sawyer::Attribute::Storage<>
typedef SynchronizationTraits < Sawyer::SingleThreadedTag >  Sync
Static Public Member Functions inherited from Sawyer::SmallObject
static SynchronizedPoolAllocator &  poolAllocator ()
Return the pool allocator for this class. More...
static void *  operator new (size_t size)
static void  operator delete (void *ptr, size_t size)

pure virtual
Returns true if two expressions must be equal (cannot be unequal).
If an SMT solver is specified then that solver is used to answer this question, otherwise equality is established by looking only at the structure of the two expressions. Two expressions can be equal without being the same width (e.g., a 32bit constant zero is equal to a 16bit constant zero).
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Returns true if two expressions might be equal, but not necessarily be equal.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Tests two expressions for structural equivalence.
Two leaf nodes are equivalent if they are the same width and have equal values or are the same variable. Two interior nodes are equivalent if they are the same width, the same operation, have the same number of children, and those children are all pairwise equivalent.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Compare two expressions structurally for sorting.
Returns 1 if this
is less than other
, 0 if they are structurally equal, and 1 if this
is greater than other
. This function returns zero when an only when isEquivalentTo returns zero, but isEquivalentTo can be much faster since it uses hashing.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Substitute one value for another.
Finds all occurrances of from
in this expression and replace them with to
. If a substitution occurs, then a new expression is returned. The matching of from
to subparts of this expression uses structural equivalence, the isEquivalentTo predicate. The from
and to
expressions must have the same width.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.
Ptr Rose::BinaryAnalysis::SymbolicExpr::Node::substituteMultiple  (  const ExprExprHashMap &  substitutions,
const SmtSolverPtr &  solver = SmtSolverPtr()

)
Rewrite expression by substituting subexpressions.
This expression is rewritten by doing a depthfirst traversal. At each step of the traversal, the subexpression is looked up by hash in the supplied substitutions table. If found, a new expression is created using the value found in the table and the traversal does not descend into the new expression. If no substitutions were performed then this
expression is returned, otherwise a new expression is returned. An optional solver, which may be null, is used during the simplification step.
Ptr Rose::BinaryAnalysis::SymbolicExpr::Node::renameVariables  (  ExprExprHashMap &  index,
size_t &  nextVariableId,
const SmtSolverPtr &  solver = SmtSolverPtr()

)
Rewrite using lowest numbered variable names.
Given an expression, use the specified index to rewrite variables. The index uses expression hashes to look up the replacement expression. If the traversal finds a variable which is not in the index then a new variable is created. The new variable has the same type as the original variable, but it's name is generated starting at nextVariableId
and incrementing after each replacement is generated. The optional solver is used during the simplification process and may be null.

pure virtual
Returns true if the expression is a known numeric value.
The value itself is stored in the number property.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Property: integer value of expression node.
Returns the integer value of a node for which isKnown returns true. The highorder bits, those beyond the number of significant bits returned by the nBits propert, are guaranteed to be zero.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

inline
Property: Comment.
Comments can be changed after a node has been created since the comment is not intended to be used for anything but annotation and/or debugging. If many expressions are sharing the same node, then the comment is changed in all those expressions. Changing the comment property is allowed even though nodes are generally immutable because comments are not considered significant for comparisons, computing hash values, etc.
Definition at line 355 of file BinarySymbolicExpr.h.
References comment_.
Referenced by Rose::BinaryAnalysis::SymbolicExpr::Interior::create().

inline
Property: Comment.
Comments can be changed after a node has been created since the comment is not intended to be used for anything but annotation and/or debugging. If many expressions are sharing the same node, then the comment is changed in all those expressions. Changing the comment property is allowed even though nodes are generally immutable because comments are not considered significant for comparisons, computing hash values, etc.
Definition at line 356 of file BinarySymbolicExpr.h.
References comment_.

inline
Property: Userdefined data.
User defined data is always optional and does not contribute to the hash value of an expression. The userdefined data can be changed at any time by the user even if the expression node to which it is attached is shared between many expressions.
Definition at line 376 of file BinarySymbolicExpr.h.
References userData_.

inline
Property: Userdefined data.
User defined data is always optional and does not contribute to the hash value of an expression. The userdefined data can be changed at any time by the user even if the expression node to which it is attached is shared between many expressions.
Definition at line 379 of file BinarySymbolicExpr.h.
References userData_.

inline
Property: Number of significant bits.
An expression with a known value is guaranteed to have all higherorder bits cleared.
Definition at line 387 of file BinarySymbolicExpr.h.
References nBits_.

inline
Property: Userdefined bit flags.
This property is significant for hashing, comparisons, and possibly other operations, therefore it is immutable. To change the flags one must create a new expression; see newFlags.
Definition at line 398 of file BinarySymbolicExpr.h.
References flags_.
Referenced by Rose::BinaryAnalysis::SymbolicExpr::Interior::create(), and Rose::BinaryAnalysis::SymbolicExpr::Leaf::createBoolean().
Ptr Rose::BinaryAnalysis::SymbolicExpr::Node::newFlags  (  unsigned  flags  )
Sets flags.
Since symbolic expressions are immutable it is not possible to change the flags directly. Therefore if the desired flags are different than the current flags a new expression is created that is the same in every other respect. If the flags are not changed then the original expression is returned.

inline
Property: Width for memory expressions.
The return value is nonzero if and only if this tree node is a memory expression.
Definition at line 412 of file BinarySymbolicExpr.h.
References domainWidth_.

inline
Check whether expression is scalar.
Everything is scalar except for memory.
Definition at line 417 of file BinarySymbolicExpr.h.
References domainWidth_.

pure virtual
Traverse the expression.
The expression is traversed in a depthfirst visit. The final return value is the final return value of the last call to the visitor.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

pure virtual
Computes the size of an expression by counting the number of nodes.
Operates in constant time. Note that it is possible (even likely) for the 64bit return value to overflow in expressions when many nodes are shared. For instance, the following loop will create an expression that contains more than 2^64 nodes:
When an overflow occurs the result is meaningless.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.
uint64_t Rose::BinaryAnalysis::SymbolicExpr::Node::nNodesUnique  (  )
Number of unique nodes in expression.
std::set<LeafPtr> Rose::BinaryAnalysis::SymbolicExpr::Node::getVariables  (  )
Returns the variables appearing in the expression.

inline
Dynamic cast of this object to an interior node.
Returns null if the cast is not valid.
Definition at line 471 of file BinarySymbolicExpr.h.
References Sawyer::SharedPointer< T >::dynamicCast(), and Sawyer::SharedFromThis< Node >::sharedFromThis().

inline
Dynamic cast of this object to a leaf node.
Returns null if the cast is not valid.
Definition at line 483 of file BinarySymbolicExpr.h.
References Sawyer::SharedPointer< T >::dynamicCast(), and Sawyer::SharedFromThis< Node >::sharedFromThis().

inline
Returns true if this node has a hash value computed and cached.
The hash value zero is reserved to indicate that no hash has been computed; if a node happens to actually hash to zero, it will not be cached and will be recomputed for every call to hash().
Definition at line 490 of file BinarySymbolicExpr.h.
References hashval_.
Hash Rose::BinaryAnalysis::SymbolicExpr::Node::hash  (  )
Returns (and caches) the hash value for this node.
If a hash value is not cached in this node, then a new hash value is computed and cached.

inline
Combines a node with a formatter for printing.
This is used for convenient printing with the "<<" operator. For instance:
Definition at line 527 of file BinarySymbolicExpr.h.
References Sawyer::SharedFromThis< Node >::sharedFromThis().
Referenced by operator+().

inline
Combines a node with a formatter for printing.
This is used for convenient printing with the "<<" operator. For instance:
Definition at line 528 of file BinarySymbolicExpr.h.
References withFormat().

pure virtual
Print the expression to a stream.
The output is an Sexpression with no linefeeds. The format of the output is controlled by the mutable Formatter argument.
Implemented in Rose::BinaryAnalysis::SymbolicExpr::Leaf, and Rose::BinaryAnalysis::SymbolicExpr::Interior.

inline
Print the expression to a stream.
The output is an Sexpression with no linefeeds. The format of the output is controlled by the mutable Formatter argument.
Definition at line 541 of file BinarySymbolicExpr.h.
References print().
Referenced by print().
void Rose::BinaryAnalysis::SymbolicExpr::Node::assertAcyclic  (  )
Asserts that expressions are acyclic.
This is intended only for debugging.
std::vector<Ptr> Rose::BinaryAnalysis::SymbolicExpr::Node::findCommonSubexpressions  (  )
Find common subexpressions.
Returns a vector of the largest common subexpressions. The list is computed by performing a depthfirst search on this expression and adding expressions to the return vector whenever a subtree is encountered a second time. Therefore the if a common subexpression A contains another common subexpression B then B will appear earlier in the list than A.
bool Rose::BinaryAnalysis::SymbolicExpr::Node::matchAddVariableConstant  (  LeafPtr &  variable,
LeafPtr &  constant
)
Determine whether an expression is a variable plus a constant.
If this expression is of the form V + X or X + V where V is a variable and X is a constant, return true and make variable
point to the variable and constant
point to the constant. If the expression is not one of these forms, then return false without modifying the arguments.
InteriorPtr Rose::BinaryAnalysis::SymbolicExpr::Node::isOperator  (  Operator  )
True (nonnull) if this node is the specified operator.

protected
Number of significant bits.
Constant over the life of the node.
Definition at line 220 of file BinarySymbolicExpr.h.
Referenced by nBits().

protected
Width of domain for unary functions.
E.g., memory.
Definition at line 221 of file BinarySymbolicExpr.h.
Referenced by domainWidth(), and isScalar().

protected
Bit flags.
Meaning of flags is up to the user. Loworder 16 bits are reserved.
Definition at line 222 of file BinarySymbolicExpr.h.
Referenced by flags().

protected
Optional comment.
Only for debugging; not significant for any calculation.
Definition at line 223 of file BinarySymbolicExpr.h.
Referenced by comment().

protected
Optional hash used as a quick way to indicate that two expressions are different.
Definition at line 224 of file BinarySymbolicExpr.h.
Referenced by isHashed().

protected
Additional userspecified data.
This is not part of the hash.
Definition at line 225 of file BinarySymbolicExpr.h.
Referenced by userData().

static
These flags are reserved for use within ROSE.
Definition at line 246 of file BinarySymbolicExpr.h.

static
Value is somehow indeterminate.
E.g., read from writable memory.
Definition at line 249 of file BinarySymbolicExpr.h.

static
Value is somehow unspecified.
A value that is intantiated as part of processing a machine instruction where the ISA documentation is incomplete or says that some result is unspecified or undefined. Intel documentation for the x86 shift and rotate instructions, for example, states that certain status bits have "undefined" values after the instruction executes.
Definition at line 255 of file BinarySymbolicExpr.h.
Referenced by Rose::BinaryAnalysis::InstructionSemantics2::SymbolicSemantics::SValue::instance_unspecified().

static
Value represents bottom in dataflow analysis.
If this flag is used by ROSE's dataflow engine to represent a bottom value in a lattice.
Definition at line 259 of file BinarySymbolicExpr.h.
Referenced by Rose::BinaryAnalysis::InstructionSemantics2::SymbolicSemantics::SValue::instance_bottom().

static
Usersupplied predicate to augment alias checking.
If this pointer is nonnull, then the mayEqual methods invoke this function. If this function returns true or false, then its return value becomes the return value of mayEqual, otherwise mayEqual continues as it normally would. This userdefined function is invoked by mayEqual after trivial situations are checked and before any calls to an SMT solver. The SMT solver argument is optional (may be null).
Definition at line 274 of file BinarySymbolicExpr.h.
